Description

Rated Temperature

75oC

Standard:

UL444,TIA/EIA568B.2,YD/T1019-2001

Conductor:

Solid Bare copper

AWG:

24

Shield:

Pe-Tape + Al foil + Pe-Tape

Insulation:

HDPE

Twisted pair

Four

Drain wire:

Solid Tinned copper

Jacket:

PVC

Rip cord:

Per request

Electrical Characteristic

1.0-100.0MHz Impedance (ohms)

100+/-15

1.0-350.0MHz Delay Skew (ns/100m)

<=45

Pair-to-Ground Capacitance Unbalance (pF/100m)

<=330

Max. Conductor DC Resistance 20oC (ohms/km)

93.8

Resistance Unbalance (%)

<=5

Application

100Base-T4

100Bsdr-TX

100VG-AnyLAN

155Mbps ATM

622Mbps ATM

Electrical Characteristics

Frequeney

Impedance

RL

Attenuation

Next

Elfext

Psnext

Delay

MHz

ohm

dB

dB/100m

dB

dB

dB

Ns/100m

0.772

100+/-15

19.4

1.8

67

64

66

574

1

20

2

65.3

62.3

63.8

570

4

23

4.1

56.3

53.3

51.7

552

8

24.5

5.8

51.8

48.8

45.7

546

10

25

6.5

50.3

47.3

43.8

545

16

25

8.2

47.3

44.3

39.7

543

20

25

9.3

45.8

42.8

37.7

542

25

24.3

10.4

44.3

41.3

35.8

541

31.3

23.6

11.7

42.9

39.9

33.9

540

62.5

21.5

17

38.4

35.4

27.8

538

100

20.1

22

35.3

32.3

23.8

537
